Description
Latest High-Efficiency Class A/B TopologyCompact Size with Ambient backlit logoRCA Pass Thru output for easy system expansionFully Variable Crossovers (12dB per octave)Handles HI and LO level input to 12V2 O Stable Stereo and 4O Mono (CH3/4) for 3 CH modeProprietary Vega Bass Boost EQ Up To 12dBSPECIFICATIONS800 MAX Power2 Channel Amplifier85W x 2 at 2Ohm RMS60W x 2 at 4OHm RMS180W x 1 at 4Ohm RMS Bridged Mono2-Ohm Stereo, 4-Ohm Bridged Full Range OperationDirect Short, Thermal, & Overload Circuits Protect Amplifier200mV-6V High Level or Low-Level RCA InputVariable 12dB High, Low, & Subsonic CrossoversFuse - 30 amp x 1Dimensions: 7.88 x 9.38 x 2.25 in (200mm x 238mm x 57mm)
