Description
VMAX15D4 | CERWIN VEGA 15in VMAXX SERIES 4 OHM DVC SUBWOOFER 3000W MAX
VMAX15D4 – 15” DUAL 4-Ohm High-Performance Subwoofer 3000W MAX / 1500W RMS
Features:
Heavy Industrial Strength Aluminium Cast Frame
Treated Semi-Pressed Pulped Cone
Elevated Motor Structure for Increased Cooling
Oversized Spider
Black Coated 3-inch Voice Coil for Higher Thermal Capability
Oversized Polished Black Chrome Distortion
Polished Bumped Backplate
Klippel Optimized Motor / Suspension Symmetry
Specifications:
SPL (dB): 86.6
Re(O)[series]: 2 Ohm / 8 Ohm
Qms: 3.98
Qes: 1.005
Qts: 0.803
Fs(Hz): 31.48
Vas(L): 94.907
Cms(mm/N): 97.11
Mms(g): 317.7
Sd(m2): 0.083
BL(T*M): 19.3
Xmax(mm): 14
Pwr(W) NOM/MAX: 1500RMS / 3000W
Displacement: 0.15 ft 3” (4.24L)
Mounting Depth (D): 7.48” (190) in. (mm)
Mounting Diameter (B): 13.98” (355) in. (mm)
Screw Hole Diameter (C): 0.26” (6.5) in. (mm)
Total Diameter (A): 15.95: (405) in. (mm)
Amplifier options:
For 1 sub can use CVPRO3K for 2 Ohm Load
