078M | BRAMLEY SJ.2 UNIVERSAL SWAGE, JENNY & WIRING MACHINE MOTORISED (2022) Bramley Model 078M - SJ2 powered16 swg /1.6 mm capacity - supplied with heavy-duty 750W (1HP), 3Ph motor and reduction gearbox to drive the rollers at 38rpm, controlled via interlocked forward / reverse footswitches.
**Note, the 078M is shown mounted on an optional stand (Part No. 060) which is available for separate purchase.**
High quality, robust, industrial duty machines, manufactured from steel, which provides good strength and long lifeThe newly re-designed SJ2 has been manufactured to deliver maximum versatility. With the locking levers down, it will edge swage & Jenny 1.6mm sheetmetalSupplied with comprehensive range of wheel attachmentsIncluded with each machine:
2mm Wiring Top and Bottom 78-31 & 78-324mm Wiring Top and Bottom 78-33 & 78-347mm Wiring Top and Bottom 78-35 & 78-3610mm Wiring Top and Bottom 78-41 & 78-421x Jenny Roller Bottom 78-381x Closing Roller Bottom 78-392x Crimping 78-40 2x Necking 78-43 & 78-442x Bearing Blocks1x Flat Roller Top
Blank Wheels for 078 - SJ2 available on request as well as above with codes - please give us a call to arrange
