Description
6311-9.00 BORDO HAND REAMER 9mm
For countersinking and deburring in a wide range of materials including ferrous and non-ferrous metals.
The intersection of the hole and cone form the cutting edge on the tool.
The cone is not truly symmetrical as it is essential that the cone retreats away from the cutting edge as the tool rotates.
If this does not occur the cutting edge will lack clearance and rub rather than bite into the material. This clearance is referred to as cutting relief.
The radially relieved single cutting edge provide fast stock removal with low vibration for chatter- free operation ensuring the smoothest finish.
Titanium Nitride (TiN) Coated Countersinks have a very hard gold coloured surface finish.
This coating is only a few microns thick and is achieved by Physical Vapour Deposition (PVD).
This treatment results in reduced friction, greater heat dissipation and reduced cold welding - which means higher speed and feed rates with greatly increased tool life.
As with all surface coated tools, performance will deteriorate after resharpening.
Material: HSS
Flute Type: 10 Degree Left Hand Spiral
Cutting Direction: Right Hand
Hole Limit: H7
Diameter: 9.00mm
Fluted Length: 62mm
Overall Length: 124mm
